Top 10 3 Hp Submersible Well Pump

SUBMERSIBLE WIRE SPLICE KIT INCLUDED WITH EVERY PUMP PURCHASE!

IMPORTANT: THIS PUMP DOES NOT REQUIRE A CONTROL BOX!

Our Deep Well Pump is ideal for the supply of fresh water to rural homes, farms, and cabins that have 4 inch and greater diameter drilled wells. It is a durable workhorse that will keep you in flow for years to come. Brand new pump in the box! NOT ‘Manufacturer Refurbished’.

-The pump has a thermally protected motor with a 95°F maximum work temperature to keep from overheating while in use.

-2-wire + ground wire design for easy provision and energy efficiency.

-Stainless steel casing keeps this pump sturdy and functioning for years.

-The well pump submersible is easy to install and extremely versatile.

-Patented impeller design provides high flow up and high head, for better performance and longer life than most other well pumps.

-This pump model features a built in check valve, however this check valve is only used to prevent water from going back in the pump and causing backspin of the impellers, but if you are going to use the pump in a pressure system YOU NEED TO USE AT LEAST ONE EXTERNAL CHECK VALVE IN THE PIPE, the valve in the pump won’t fulfill that function.

-1 year warranty.

NOTICE: Our pumps are checked for physical damage before they’re shipped. As soon as you receive it check for any damage that might have occurred during shipping, and please report it to Amazon if you see any.

NOTICE 2: This pump is designed to be used in clear pure water only, even an small amount of sand diluted in the water will damage it, make sure your well pumps clear water before you install it, this is important because damages caused by sand are not covered by the warranty.

4″ deep well submersible pump. 2 HP, 230V, 10.2 Amps, 12 stage, 1-1/4” NPT discharge Industrial grade heavy duty, also good for home usage
* Fits a 5″ or larger well casing.
* Patented impeller & 12 stage design. 35GPM max & 400ft head are greater than almost all other 2HP well pumps, and comparable to 3HP pumps, but uses less electricity.
* Unique floating impeller design, premium seal, and UL qualified motor provide long life for this pump.
* Water temperature: (32 ~113of) Trans medium’s Ph.: 6.5~ 8.5
* Shell, motor shaft are made with stainless steel to ensure corrosion resistance.
* High quality sealed ball bearings guarantee its excellent performance.
* Built in check valve included. Installing external check valve(s) is required.
* Hermetically sealed motor with capacitor start, and thermal protection to prevent overheating, for longer life and powerful start.
* Built in control box. This pump DOES NOT require an external control box!
* This pump uses high quality and high efficient UL approved motor, UL file No.: E233961, for less energy and long pump life.
* This is a 2 wire pump with 3-Wire (2 wires + ground wire) 10′ long electric cord included.
* Heavy-duty thermoplastic impellers, diffusers, and intake screen.
* Unique design reduces its noise. User’s manual and installation tape kit included.
* 400 feet max head is for open water tanks. Refer to the ‘Pump Selection Guide’ for the pressure tank applications.
* Warranty: 12 months manufacturer’s warranty

1HP, 115V/60HZ/1PH, 7 stage, 33 GPM Max, 207 feet head, Mid Intake, S.S. SHELL C.I Intake, 1-1/4” NPT discharge.
Warning: This is 110V pump! Using 220V will burn the pump!
Specifications:
* 4″ deep well submersible pump. 1 HP, 115V, 10.3 Amps, 7 stage, 1-1/4” NPT discharge Industrial grade heavy duty, also good for home usage
* Fits a 5″ or larger well casing. For 4″ casing, use pump MA0460X-9, or MA0459X-14;
* Patented impeller provides high flow up to 33GPM, and 207 ft. Head. That is greater than almost all other 1 HP well pumps.
* Water temperature: (32 ~113of) Trans medium’s Ph.: 6.5~ 8.5
* Shell, motor shaft are made with stainless steel to ensure corrosion resistance.
* High quality sealed ball bearings guarantee its excellent performance.
* High efficient and hermetically sealed motor has a built in capacitor start, and thermal protection to prevent overheating, for longer life and powerful start.
* Built in control box. This pump DOES NOT require an external control box!
* This pump uses high quality UL approved motor, UL file No.: E233961
* This is a 2 wire pump (2 wires + ground wire) 10′ long electric cord included.
* Heavy-duty thermoplastic impellers, diffusers, and intake screen.
* Built in check valve included.
* Submersible design creates quiet operation
* Unique design reduces its noise.
* 207 feet max head is for open water tanks. Refer to the ‘Pump Selection Guide’ for the pressure tank applications.
* User’s manual included and installation tape kit included.
* Warranty: 12 months limited manufacturer’s warranty

1HP, 230V/60HZ/1PH, 7 stage, 33 GPM Max, 207 feet head, Mid Intake, S.S. SHELL C.I Intake, 1-1/4” NPT discharge.
Warning: This is 220V pump!

Specifications:
* 4″ deep well submersible pump. 1 HP, 230V, 5.1 Amps, 7 stage, 1-1/4” NPT discharge Industrial grade heavy duty, also good for home usage
* Fits a 5″ or larger well casing. For 4″ casing, use pump MA0460X-9A, or MA0459X-14A;
* Patented impeller provides high flow up to 33GPM, and 207 ft. Head. That is greater than almost all other 1 HP well pumps.
* Water temperature: (32 ~113of) Trans medium’s Ph.: 6.5~ 8.5
* Shell, motor shaft are made with stainless steel to ensure corrosion resistance.
* High quality sealed ball bearings guarantee its excellent performance.
* High efficient and hermetically sealed motor has a built in capacitor start, and thermal protection to prevent overheating, for longer life and powerful start.
* Built in control box. This pump DOES NOT require an external control box!
* This pump uses high quality UL approved motor, UL file No.: E233961
* This is a 2 wire pump (2 wires + ground wire) 10′ long electric cord included.
* Heavy-duty thermoplastic impellers, diffusers, and intake screen.
* Built in check valve included.
* Submersible design creates quiet operation
* Unique design reduces its noise.
* 207 feet max head is for open water tanks. Refer to the ‘Pump Selection Guide’ for the pressure tank applications.
* User’s manual included and installation tape kit included.
* Warranty: 12 months limited manufacturer’s warranty
